J-CAT STELLAR

Desktop Soldering Robot J-CAT STELLAR

This robot is high-powered model of the J-CAT COMET.

A 200 watt heater can be added as an attachment, and this machine is able to use the larger 2.0mm solder diameter. This machine is most useful in soldering high sink applications such as multilayer board and shielding case.

J-Cat Stellar Specifications
Robot J-Cat 200 Stellar X=200mm, Y=200mm, Z=50mm, R=+/-360°
Move J-Cat 300 Stellar X=300mm, Y=320mm, Z=100mm, R=+/-360°
Area J-Cat 400 Stellar X=400mm, Y=400mm, Z=100mm, R=+/-360°
Program and Memory Capacity 255 programs
30,000 maximum points
Soldering Condition Point and slide
297 total conditions
Power and Consumption AC90 – 132V, AC180 – 250V, 200W
Standard equipment
200W high capacity heater
High power solder feeder can feed maximum 2.0mm diameter
Sequence function is equipped to work independently from robot
